Why geotextiles earn their place in civil engineering

Geotextiles are the quiet achievers of civil engineering. Buried under roads, behind retaining walls, wrapped around drains and laid beneath railway ballast, they perform a set of jobs that would otherwise be done by thick layers of imported stone or by concrete. A well-chosen geotextile can separate a soft subgrade from a granular fill, filter water while holding back soil particles, reinforce a weak formation, or allow water to flow in-plane to a drainage outlet. The result is a thinner, more durable and more predictable construction.

But geotextiles are not a single product. Woven and nonwoven types behave differently, and a specification that suits a motorway embankment may be quite wrong for a French drain in heavy clay. The right choice depends on the functions required and the ground and load conditions they will meet.

The core functions: separation, filtration and reinforcement

Most geotextile applications combine two or more functions, but it helps to name them clearly.

• Separation: A geotextile placed between a soft subgrade and a granular capping layer prevents the two from mixing. Without it, traffic and water can pump fines into the stone, destroying the drainage and load-spreading properties of the fill.
• Filtration: The fabric allows water to pass while retaining soil particles. This is essential in drains, behind retaining structures and around drainage blankets, where a filter that clogs or washes out will fail.
• Reinforcement: A geotextile with adequate tensile strength and low creep can carry part of the load, bridging soft spots and reducing differential settlement. This is common in unpaved roads, working platforms and embankments on weak ground.
• Drainage: Thick nonwoven geotextiles can transmit water in their own plane, acting as a drainage layer or a protective cushion for a geomembrane.
• Protection: In landfill and reservoir liners, a geotextile cushions the geomembrane against puncture from angular stone.

In roads and drains, separation and filtration usually lead. Reinforcement matters most when the subgrade is very soft or loads are heavy.

Woven versus nonwoven: a practical comparison

Woven geotextiles are made from interlaced yarns. They tend to offer high tensile strength at low elongation, which makes them well suited to reinforcement and separation where the fabric must resist stretching. Their apertures are relatively uniform, so they can be tailored for filtration, but they can also be stiff and less able to conform to an uneven subgrade.

Nonwoven geotextiles are made from randomly oriented fibres, usually bonded mechanically, thermally or chemically. They are thicker, more permeable and more extensible. That makes them excellent filters and drainage layers, and their bulk helps them survive installation damage. They are often the better choice for filtration around drains, for cushioning geomembranes and for separating fine-grained soils from coarse fill.

Neither type is superior. A nonwoven may filter well but lack tensile strength; a woven may reinforce well but clog with fine plastic soil. The soil and load decide.

Specifying from the soil up

Start with the soil. Particle size distribution and plasticity index show whether the ground will form a stable filter cake or pump fines through the fabric. For filtration, the geotextile’s characteristic opening size, often O90 or AOS, must retain soil while passing water. A common starting point is an opening size less than about two to three times the D85 of the soil, checked against the actual gradation and hydraulic gradient.

Loads then guide the grade. A temporary haul road over soft clay needs high tensile strength and puncture resistance. A drainage trench in sandy gravel needs filtration and permeability. A landfill cap needs protection and durability.

Test methods help turn these needs into a specification. Look for mass per unit area, tensile strength, CBR puncture resistance, water permeability normal to the plane, characteristic opening size and, where relevant, in-plane flow capacity. Also check seam strength if panels will be joined. In the UK, specifications often reference European standards, and a good supplier will provide test data rather than vague claims.

Installation and durability: where good intentions fail

Even the right geotextile can underperform if it is installed badly. Subgrade should be trimmed and cleared of sharp objects. Overlaps must be adequate for the application, often 300 to 500 mm for separation and filtration, and more where settlement is expected. Where seams are required, they should be sewn or thermally bonded to develop the specified strength.

Construction traffic should not run directly on the fabric unless it is designed for that. A layer of granular fill should be placed over it before tracked or wheeled plant moves across. UV exposure matters if the fabric will be left open for more than a few weeks; otherwise, UV stabilisation is mainly a handling and storage consideration.

Durability also depends on chemical conditions. Most common geotextiles resist the pH range in soils and groundwater, but acidic or alkaline environments, hydrocarbons and high temperatures may need a different polymer. Design life should guide the choice, not just price per square metre.

Getting the specification right

Geotextiles work best when they are treated as engineered components, not as a generic membrane. Define the function, characterise the soil, quantify the loads, and select a material with the opening size, permeability, strength and durability to match. Check installation damage assumptions and seam details. Then verify the product data against the specification.

Do that, and a thin fabric can replace hundreds of millimetres of imported stone, keep a drain flowing for decades, and hold a road together over ground that would otherwise rut. It is a small cost that protects the whole asset.
